Modern, modular, convex seat design. Mix and match upholstery fabrics, multipurpose compact laminates, solid surfaces, and powder-coat colours.

Botton + Gardiner

Product Specifications

Description

Modest modularity and organic forms define the Nexus convex seat that can be integrated with other modular lounge seating elements, tables, planters and litter bins that interconnect in multiple ways to become a central meeting place in a range of indoor spaces. Suitable for shopping centre breakout areas, educational collaborative spaces, transit zones and commercial lobbies, Nexus is both highly versatile and flexible. Available in an extensive range of hard-wearing materials, finishes and colours, Nexus can be customised to suit your next interior project.

Made In Australia
Dimensions

2700mmW x 1040mmD x 835mmH

Seat height: 450mm
Seat depth including backrest: 730mm
Seat depth from front of seat to backrest: 530mm to 565mm due to tapered backrest.

Frame

Internal Frame
Medium Density Fibreboard (MDF)

Kick Plate
Powder-coated aluminium

Armrest Base
Powder-coated steel

Powder Coat

Core
White (satin), Black (satin), Charcoal (satin), Palladium Silver (satin), Matt Black (matt), Pearl White (gloss)

Solid
Coffee (satin), Cove (satin), Monument (matt), Medium Bronze Kinetic (flat)

Textured
Core Ten (textured metallic), Asteroid (textured metallic), Bass (textured metallic), Textura Black (textured), Textura Monument (textured), Textura White (textured)

Signature
Deep Ocean (satin), Wedgewood (satin), Mangrove (satin), Territory Red (matt), Claypot (satin), Paperbark (satin)

Bold
Bondi Blue (gloss), Leaf (satin), Sensation (gloss), Lobster (satin), Moonlight (satin)

Fabric Amount Required

7.0m - based on one plain fabric 137cm wide.

Finishes

Upholstery Fabrics
Specify a Baresque upholstery fabric or supply your own to be approved by us to ensure it is fit for purpose.

Baresque
Meru - Lake, Abyss, Charcoal, Root, Nickel, Vellum, Chablis, Caribbean, Emerald, Tranquil, Nectar, Fiesta

Approved Baresque Fabric Collections
Abilene, Cassidy, Castle, Chamois, Gleam Beyond, Lara, Meru, Ranger Inception Galleria, Sebago, Spirit Vinyl Up, Uptown 3, Yosemite.

Armrest Top
Multipurpose Compact Laminate 13mm I Laminex®
Licorice Linea, Natural Walnut, Elegant Oak, Classic Oak, Calm Oak, Seasoned Oak, Black, Charcoal, Lava Grey, Limed Concrete, Figured Limestone, White Valencia

Solid Surfaces 12mm | Corian®
Basalt Terrazzo, Platinum, Silver Birch, Silver Grey, Pearl Grey, Glacier White, Deep Anthracite, Deep Titanium, Carbon Aggregate, Dove, Neutral Concrete, Canvas

A wider selection of materials + finishes is available.

Sustainability

Certified Materials
We use multipurpose compact laminates and non-porous solid surfaces that carry internationally recognised Environmental Product Declarations (EPDs).

Recycled Materials
We locally source our steel and aluminium. It means we know it uses recycled content and is 100% recyclable.

Low Pollutants
Our powder-coating process doesn’t emit Volatile Organic Compounds (VOCs) and has Environmental Product Declarations (EPDs).

Warranty

2-year warranty. View the warranty for more details.

Lead Time

6-8 weeks

Assembly & Delivery

Shipped fully assembled on pallets.

Fixing Detail

Freestanding only - loose on glides. Modules are fixed together by ratchet connectors.

How to Specify

Select your configuration or create your own
Select your fit for purpose upholstery fabric
Select optional armrests
Select optional power
Select your surface finish
Select your frame finish

Care Instructions

Baresque Upholstery Fabrics
Use a cloth with any of the following in preferred order of use:
1. Clear warm water
2. Mild solution of liquid detergent and warm water
3. Isopropyl Alcohol (rubbing alcohol)

Remove any detergent with a clean, damp cloth. Gently pat dry.

For more difficult stains, dampen a soft white cloth with a solution of household bleach (mix 10% bleach with 90% water). Rub gently. Rinse with a water dampened cloth to remove bleach concentration.

Do not use solvent based or concentrated abrasive cleaning agents, lacquer thinners or nail polish remover as these may cause discolouration over a period of time.

Always test in an inconspicuous area first.

Multipurpose Compact Laminates | Laminex®
A damp cloth will remove spills and greasy spots. Rub with a clean dry cloth to bring back brightness. Occasionally clean with mild dishwashing detergent. To remove heavy build-up of dirt use cleaners such as Mr Muscle, Windex, or Ajax Spray n Wipe spray cleaners.

Do not use strong acidic, alkaline cleaners or bleach for normal cleaning as these might etch the surface.

Solid Surfaces | Corian®
Generally, when caring for Corian always start with a simple clean eg. using a damp sponge or cloth.  Avoid using abrasive scouring pads for routine cleaning. Rinse clean.

For a deep clean of stubborn stains, a more thorough clean and refresh using a mild abrasive cleanser is recommended like Gumption, JIF Cream Cleanser or Ajax cream or powder cleanser. Firmly wipe with a damp cloth using a wide circular motion. Always finish by rinsing and wiping your surface with a damp cloth or sponge.

Powder-Coat Finishes
Carefully remove any loose surface deposits with a wet sponge or soft bristled brush.

Use a soft (non-abrasive) cloth or brush and a diluted solution of mild detergent and warm water.

Ensure surfaces are thoroughly rinsed with clean fresh water after cleaning to remove all residues.

Never use thinners, abrasive cleaning agents, alcohol-based, acid or alkali cleaning agents.

Additional Comments

Commercial-grade, high-density foam with a dacron top layer is used for padding and comfort.
